Ball Valve

>> General

Series DRO-01 General Service Ball Valves Are Designed Side Entry Type That A Casted Two-Piece, It Is Available In Size From 1/2" To 8" That Is Full Or Reduced Type.

Its Offer Ansi Class Rating Up To 600Lb And Temperature Ratings Of -46℃ To 200℃.

Serial Floating Ball Valves Are Mainly Applied To Natural Gas, Oil Products Chemical Engineering, Metallurgy, City Building, Environment Protection Pharmacy And Food Industries, Among Which The Anti-Sulphur Series Are Used For Long Delivery Pipes Of Natural Gas That Contains Hydrogen Sulphide Medium, A Lot Of Impurity And Corrosive Substances.

>> Performance

- High Cv Body Size Ratio. (Full Bore)

- Controls Through 90° Rotation.

- Easy Maintenance.

>> Specifications

Valve Model		Series DRO
Valve Type		FULL, REDUCE
Valve Size		1/2"(15A) to 24" (600A)
Valve Rating		ANSI 150# to 600# JIS 10K to 40K PN 10 to 40
End Connection		RF, FF, SW, BW, Screw, RTJ, and so on
Body Material		WCB, CF8, CF8M, CF3, CF3M, CD4MCU and so on SCPH2, SCS13, SCS14, SCS19, SCS16, SCS1, SCS2 and so on 304, 316, 316L, 420J2 and so on SPPS380, MONEL, HASTELLOY, TITANIUM, ALLOY 20, MORE-1 and so on +STL, +TCC, +RUBBER, +TFE, +PFA, +CERAMIC and so on
Ball Material		CF8, CF8M, CF3, CF3M, CD4MCU, CA6NM and so on SCS13, SCS14, SCS19, SCS16, SCS1, SCS2 and so on 304, 316, 316L, 420J2 and so on MONEL, HASTELLOY, TITANIUM, ALLOY 20, MORE-1 and so on +STL, +TCC, +RUBBER, +TFE, +PFA, +CERAMIC and so on
Seat		PTFE, RTFE, CTFE, PEEK and so on 304, 316, 316L, 420J2 and so on MONEL, HASTELLOY, TITANIUM, ALLOY 20, MORE-1 and so on +STL, +TCC, +RUBBER, +TFE, +PFA, +CERAMIC and so on
Bonnet Type		Plain (-17℃ to 230℃)
		Extension ( -45℃ to -17℃, over 230℃)
		Cryogenic ( -196℃ to -45℃)
Flow Characteristic		Approximative, On-off
Leakage Class	Metal Seat	Rated ANSI Class IV
Leakage Class	Soft Seat	Rated ANSI Class VI
Actuator Combination		Spring Return Cylinder, Double Acting Cylinder, Electric Actuator,Gear
